Description
INTRODUCTION & TECHNICAL SPECIFICATION
| Model | DX-HPR1000 | DX-HPR1200 |
| Size After Packaging | 450x1450x1200mm, 350kg | 450x1650x1200mm, 430kg |
| Occupation Size | 1600x1450x1200mm, 350kg | 1600x1650x1200mm, 430kg |
| Speed | 30 m/min (the slower, the better) | 30 m/min (the slower, the better) |
| Maximum Value of Hydraulic Pressure Gauge | 1-2Mpa | 1-2Mpa |
| Voltage | 380v/50hz | 380v/50hz |
| Power | 4.5KW | 4.5KW |
| Size of Feeding Plate | 600x1150mm | 600x1350mm |
| Size of Receiving Plate | 1100x1000mm | 1100x1200mm |
Note:
The roller is heated by the lamp tube: the middle temperature is high, the temperature on both sides is low, and it is not recommended to remove powder at the same time. The heat will not be uniform, and the powder removal effect is not good.
