INTRODUCTION & TECHNICAL SPECIFICATION
- Advanced machine structure, perfect outlooking and high precision manufacturing.
- High quality parts.
- The whole process is controlled by industrial computer with high precision.
- Main and minor traction can be set length, adopt AC servo motor and drive.
- Horizontal positioning, using German Hikvision photoelectric sensors with high positioning accuracy.
- Heating board and sealing knife are made of Al. Magnesium alloy with high strength and high quality sealing.
- The machine which is with times sending function can produce super longer packaging bag.
- All electric parts and pneumatic parts adopt imported brand and overseas cooperation brand.
Size of Bag | 75-600mm Three Side Sealing Bag Width
Second Time Sealing 340(Pass 340mm By Using Times Sending) |
Size of Winging | Width 1100-1400mm Diameter 800mm |
Capacity | Machine Speed: 80-280 Cuts/min
Bag Capacity: 80-240 Cuts/min |
Feed Speed | 46m/min |
Main Motor Power | 4.0KW |
Total Power | 48KW |
Size of Machine | L16.5m x W1.9m x H2.0m |
Weight | About 5500 kgs |
