Description
INTRODUCTION & TECHNICAL SPECIFICATION
It’s newest upgrading model for water base lamination. The equipment has the characteristics of high performance and high efficiency. To meet the professional needs of print surface finishing, to bring your company’s laminating product quality level to a new level. It not only saves manpower and material resources, but also greatly shortens the production cycle.
1). Laminating Part
| Model | 1100 |
| Max. Laminating Width | 1050x880mm |
| Min. Laminating Width | 290x350mm |
| Paper Weight | 100-400g/m² |
| Laminating Speed | 20-100m/min |
| Production Speed | 100m/min |
| Laminating Method | Cold/Water Soluble Glue |
| Voltage | AC380V/3PH/50HZ |
| Gross Power | 8.1Kw |
| Total Weight | 2400kg |
| Overall Dimensions | L4710 x W1900 x H2340 |
2). Paper Separating Part
It’s auxiliary model of laminating machine and suitable for separating different paper with stable high speed and easy operation. The machine is equipped with automatic paper delivery.
| Model | 1100 |
| Max Paper Size | L1050 x W880mm |
| Min Paper Size | L320 x W320MM |
| Paper Weight | 100-500g/m² |
| Working | 0-100m/min |
| Power | 450V/50HZ |
| Gross Power | 2Kw |
| Overall Demensions | L4500 x W1700 x H1750 |
| Total Weight | 1900kg |
